TP-Link TD-W8968 300Mbps Wireless N ADSL2+ Modem Router with USB Port (Version 1.0))

The TD-W8961ND Wireless N ADSL2+ Modem Router is an All-in-One device that combines the functions of a high speed ADSL modem, a 4-Port 10/100Mbps NAT router and a wireless access point. It is designed to provide end-users with a one-stop solution to acquiring and sharing high-speed Internet access over a wired/wireless network. Supporting the latest ADSL standards, the TD-W8961ND brings with it much higher speed than dial-up connections. Complying with the IEEE 802.11n standard, users will get up to 15X the speed and 5X the range of conventional 11g products. With this product, users can now enjoy more kinds of heavy bandwidth consuming applications like wireless HD video streaming, not possible with 11g products, from anywhere in their entire homes or even in their backyards! As a 3-in-1 device, the TD-W8961ND combines the functions of a high speed DSL modem, a 4-Port 10/100Mbps NAT router and a wireless N access point. Using a telephone line the TD-W8961ND establishes a high-speed ADSL2+ Internet connection. Once set up, the device's wired/wireless functions can be used to share media between devices, browse the Internet, talk on an IP phone, or even stream HD video. Save time and money using one device instead of multiple devices that take longer to set up and occupy more cluttered space.



Unlike dial-up Internet service, a DSL Internet connection is always on, so users need not dial up or wait to access the web. Supporting the latest ADSL standards, the TD-W8961ND provides higher performance (up to 24Mbps downstream) and longer reach from user's local Internet Service Provider (ISP). This device also supports TR-069, which automatically updates the device's firmware and other settings when they become available from the ISP. TD-W8961ND is a high-speed solution that complies with IEEE802.11n standards with wireless transmission speeds of up to 300Mbps. It adopts MIMO technology, has two detachable Omni directional antennas providing better wireless performance, transmission rates, stability and coverage. Users can get up to 15x the speed and 5x the range of conventional 11g products and share high-speed DSL Internet connections, photos, music, files, and even heavy bandwidth consuming applications like wireless HD video streaming, something not possible with 11g products, from anywhere in their entire homes or even in their backyards! Port VLAN binds specific LAN ports and PVCs for differential services like IPTV. The TD-W8961ND's built-in QoS engine provides various QoS policies that help prioritize Internet traffic to enable smooth IPTV streaming and lag-free online gaming.Features

• High speed DSL modem, NAT router and wireless access point in one device providing a one-stop networking solution
• 2.4GHz, IEEE802.11b/g/n, up to 300Mbps data transfer rates
• USB 2.0 port supports Storage Sharing (Samba or FTP), Media Server, Print Server and multi accounts
• Ethernet WAN (EWAN) offers another broadband connectivity option for connecting to Cable, VDSL or Fiber modems
• IP based Bandwidth Control makes it easier for you to manage the bandwidth of devices that connected to the modem router
• Wi-Fi On/Off Button allows users to simply turn their wireless radio on or off
• Easy one-touch WPA wireless security encryption with the WPS button
• Easy Setup Assistant with multi-language support provides a quick & hassle free installation
• SPI and NAT firewall protects end-user devices from potential attacks from the Internet
• Interface Grouping binds specific LAN ports with PVCs for an enjoyable IPTV experience
• Annex M doubles the upstream data rate
• Auto-reconnect keeps user online indefinitely
• Backward compatible with 802.11b/g products

Specifications

Compliance
Safety	CE, FCC, RoHS
Electrical
Power Adaptor Type	External
DC Input Voltage	12VDC
AC Input Current	1.5Amps
Environmental
Environmental	Humidity 10 to 90% Operating Temperature 0 to 40�C
Ethernet
Protocols Supported	ATM Forum UNI3.1/4.0 � PPP over ATM (RFC 2364) � PPP over Ethernet (RFC2516) � IPoA (RFC1577/2225) � PVC - Up to 8 PVCs � Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt � Dynamic Host Configuration Protocol (DHCP) � Network Address Translation (NAT) � DNS Relay, DDNS � IGMP snooping V1/2 � IGMP Multicast � UPnP
Ethernet Standards	IEEE 802.3, 802.3u
General
Model Name	TD-W8968
Product Type	Modem Router
Warranty	Three years.
Barcode	6935364060749
Interfaces/Ports
LAN Ports	4 port(s) x RJ-45 10/100Mbps Ethernet
USB Ports	1 x USB 2.0
Modem Port	1 x RJ-11
Physical
LED Status Indicators	Power, Internet, ADSL, WLAN, LAN1 to 4, QSS
In The Box	TD-W8968 � 2 x RJ-11 Telephone Cable � 1 x RJ-45 Ethernet Cable � Quick Installation Guide � Resource CD � 1 x Power Adaptor
Dimensions	19.5cm (W) x 13.0cm (D) x 3.6cm (H)
Router
Router Type	ADSL2+
Security
Security	NAT Firewall, � SPI Firewall, � MAC / IP / Packet / URL Filtering
VPN Pass Through/Multi-Sessions	PPTP � L2TP � IPSec
System
Management	Web Based Configuration (HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP over EOC, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
System Requirements
Operating Systems Supported	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
WAN
WAN Standards	ADSL Standards: Full-rate ANSI T1.413 Issue 2; ITU-T G.992.1(G.DMT); ITU-T G.992.2 (G.Lite); ITU-T G.994.1 (G.hs); ITU-T G.995.1 � ADSL2 Standards: ITU-T G.992.3 (G.dmt.bis); ITU-T G.992.4 (G.lite.bis) � ADSL2+ Standards: ITU-T G.992.5
Data Rates ADSL downstream	24Mbps
Data Rates ADSL upstream	3.5Mbps
Wireless LAN
Wireless LAN Standards:	IEEE 802.11 b g n
Frequency Band	2.4 to 2.4835GHz
Data Transfer Rates	Data Transfer Rates Up to 300Mbps
Transmit Power	20dB
Encryption	64/128-bit WEP WPA-PSK WPA2-PSK
Antenna Type	2x3dBi Omni directional, Detachable, Reverse SMA
