Avocent PM 3000 Power Distribution Unit 0U 1-PH (220 to 240V) with IEC 309 32a, 21xC13 and 3xC19 Outlets (Vertical)

The Avocent Power Management Distribution Units (PM PDUs) include single-phase and three-phase models that support strip-level metering, outlet-level metering or outlet-level metering and switching. This advanced family of rack PDUs includes horizontal and vertical models for a variety of rack configurations in branch and remote offices.



Thresholds can be created to allow data centre teams to know before problems occur and minimize downtime caused by overloaded circuits. With the ability to support up to 22 kW and support for C19 outlets, the PM 2000 and PM 3000 PDUs are well positioned to support the high rack density found in organizations today.Features

• Outlet-Level, Phase-Level and Strip-Level Current/Voltage/Power Metering with Threshold/Alert Capabilities � Provides preemptive notification of any impending overload issues before they occur and simplifies the task of installing new equipment (Note- mea
• Capability to Remotely Switch Outlets Through On-Board Web Interface, DSView 3 Management Software � Allows power to hung up IT equipment to be recycled, turned on or turned off remotely for faster resolution time (not available on PM 1000 or PM 2000 PDUs
• On-Board Web Interface � Can be installed for direct access right out of the box or it can be configured as part of a larger integrated solution using the DSView 3 management software
• Daisy Chaining � Saves the number of IP addresses or console/KVM ports that are required to manage all power distribution needs
• Integration with DSView 3 Management Software � Single interface for management of IT equipment and PDUs simplifies mapping of outlets to servers and other equipment in order to reduce and minimize power cycling the wrong equipment
• Integration with DSView 3 Software Power Manager Plug-In � Track historical trends to measure and monitor IT power consumption, capacity and cost in order to understand what issues exist and to make more informed decisions in the future
• Electronic Overcurrent Protection � An added layer of protection that is activated in the event of minor overloads; during such events, outlets are turned off first instead of the primary overcurrent protection (OCP) tripping
• Sequential Startup � Protects integrity of all upstream electrical infrastructure by staggering the inrush current draw of all plugged-in devices
• Internal Temperature Sensor and Two Optional External Sensors � These sensors can measure environmental factors at several different points within the rack

Specifications

Electrical
AC Voltage Range	220 to 240V
Maximum Input Current	32A
General
Model Name	PM 3000
Product Type	Power Distribution Unit
Barcode	636430056593
Physical
Case Colour	Black
Dimensions	8.0cm (W) x 5.6cm (D) x 167.6cm (H) - Weight 6.7kg
