Performance |
||
# of Cores | 18 | |
# of Threads | 36 | |
Processor Base Frequency | 2.30 GHz | |
Max Turbo Frequency | 3.60 GHz | |
Cache | 45 MB SmartCache | |
Bus Speed | 9.6 GT/s QPI | |
# of QPI Links | 2 | |
TDP | 145 W | |
VID Voltage Range | 0 |
-
Supplemental Information |
||
Embedded Options Available | No | |
Conflict Free | Yes | |
Datasheet | Link |
-
Memory Specifications |
||
Max Memory Size (dependent on memory type) | 1.54 TB | |
Memory Types | DDR4 1600/1866/2133/2400 | |
Max # of Memory Channels | 4 | |
Max Memory Bandwidth | 76.8 GB/s | |
Physical Address Extensions | 46-bit | |
ECC Memory Supported ‡ | Yes |
-
Graphics Specifications |
||
Processor Graphics ‡ | None |
-
Expansion Options |
||
Scalability | 2S | |
PCI Express Revision | 3.0 | |
PCI Express Configurations ‡ | x4, x8, x16 | |
Max # of PCI Express Lanes | 40 |
-
Package Specifications |
||
Sockets Supported | FCLGA2011-3 | |
Max CPU Configuration | 2 | |
TCASE | 79°C | |
Package Size | 45mm x 52.5mm | |
Low Halogen Options Available | See MDDS |
-
Advanced Technologies |
||
Intel® Turbo Boost Technology ‡ | 2.0 | |
Intel® vPro Technology ‡ | Yes | |
Intel® Hyper-Threading Technology ‡ | Yes | |
Intel® Virtualization Technology (VT-x) ‡ | Yes | |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes | |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes | |
Intel® TSX-NI | Yes | |
Intel® 64 ‡ | Yes | |
Instruction Set | 64-bit | |
Instruction Set Extensions | AVX 2.0 | |
Idle States | Yes | |
Enhanced Intel SpeedStep® Technology | Yes | |
Intel® Demand Based Switching | Yes | |
Thermal Monitoring Technologies | Yes | |
Intel® Flex Memory Access | No | |
Intel® Identity Protection Technology ‡ | No |
-
Intel® Platform Protection Technology |
||
OS Guard | Yes | |
Trusted Execution Technology ‡ | Yes | |
Execute Disable Bit ‡ | Yes |
