Supermicro Motherboard A2SDi-8C-HLN4F

MBD-A2SDI-8C-HLN4F-O

Sorry, but this product is no longer available to purchase online.

Please contact us to discuss alternative products which may be suitable.

Looking for Compatible Products?

Frequently bought together

In-Win IW-MS08 - Mini Tower Server Case w/ 8x Hot-Swap Bays (12Gbps MiniSAS HD Connection)

£210.17 ex VAT

(£252.20 inc VAT)

More from this brand

Product Description

Product SKUs

MBD-A2SDi-8C-HLN4F	A2SDi-8C-HLN4F


Physical Stats

Form Factor	Mini-ITX
Dimensions	6.7" x 6.7" (17.02cm x 17.02cm)


Processor/Cache

CPU	Intel® Atom™ Processor C3758. Single Socket FCBGA1310 supported, CPU TDP support 25W
Cores / Cache	8 cores, 8 threads / 16MB cache


System Memory

Memory Capacity	Up to 256GB Registered ECC RDIMM and DDR4-2400MHz Up to 64GB Unbuffered ECC/non-ECC UDIMM, DDR4-2400MHz, in 4 DIMM slots
Memory Type	2400/2133/1866/1600MHz
DIMM Sizes	4GB, 8GB, 16GB, 32GB, 64GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)


On-Board Devices

Chipset	System on Chip
SATA	SoC controller for 12 SATA3 (6 Gbps) ports;
IPMI	ASPEED AST2400 BMC
Network Controllers	Quad LAN with Intel® C3000 SoC 1GbE
Graphics	Aspeed AST2400 BMC


Input / Output

LAN	4 RJ45 Gigabit Ethernet LAN ports
USB	4 USB 2.0 ports (2 rear + 2 headers), 1 USB 3.0 ports ( + 1 Type A)
Video Output	1 VGA port
Serial Port / Header	1 COM Port (1 header)
TPM	TPM Header

Expansion Slots

PCI-E	1 PCI-E 3.0 x4
M.2	Interface: PCI-E 3.0 x2 and SATA Form Factor: M-Key 2242, 2280


System BIOS

BIOS Type	AMI UEFI
BIOS Features	UEFI 2.4 SMBIOS 2.7.1


Management

Software	IPMI2.0, KVM with dedicated LAN, NMI, SuperDoctor® 5, Watchdog
Power Configurations	ATX Power connector +12V DC Power Input CPU thermal trip support for processor protection Power-on mode for AC power recovery


PC Health Monitoring

Voltage	+12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, 4 -fan status, 4 fans with tachometer monitoring, Chassis intrusion header, Monitors CPU voltages, Supports system management utility, System level control, System temperature, VBAT
FAN	4x 4-pin fan headers (up to 4 fans), 4 fans with tachometer monitoring, Dual Cooling Zone, Fan speed control, Pulse Width Modulated (PWM) fan connectors, Status monitoring for speed control, Support 3-pin fans (w/o speed control), System level control, Thermal control tachometer fan connectors
Temperature	CPU thermal trip support
LED	UID/Remote UID
Other Features	12V DC or ATX Power Source, 4-pin 12v DC power connector, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Dual Cooling Zones, Innovation Engine, Intel® QuickAssist Technology , M.2 NGFF connector, RoHS, SDDC, System level control, UID, WOL


Operating Environment

Operating Temperature Range	0°C ~ 60°C (32°F ~ 140°F)
Non-Operating Temperature Range	-40°C - 85°C (-40°F - 185°F)
Operating Relative Humidity Range	10% ~ 85% (non-condensing)
Non-Operating Relative Humidity Range	10% ~ 95% (non-condensing)
