APC Smart-UPS VT 30kVA 400V with 3 Battery Modules Expandable to 4/Built-in Maintenance Bypass/Parallel Capable/Start-Up 5X8

Smart-UPS VT offers centralized three-phase power protection with the reliability of the award winning Smart-UPS family. Ideal for small data centres, large retail stores, regional offices, and dense power requirements, the Smart-UPS VT includes dual-mains input, automatic and maintenance bypasses, and scalable runtime with hot-swappable batteries for increased availability. The rack mounted version maximizes valuable floor space by incorporating UPS, power distribution, and additional battery capacity in a single rack. Low cost of ownership is achieved through best-in-class efficiency and a reduction in rating of electrical infrastructure - wires, transformers, and generators due the Smart-UPS VT's Soft Start feature. The APC Network Management Card with temperature monitoring provides remote monitoring and management through a simple Web/SNMP interface and provides integration with InfraStruXure Manager. Serviceability is greatly enhanced by user-replaceable batteries, manageable extended run frames and included start-up and standard onsite warranty services. All these features make the Smart-UPS VT the easiest UPS in its class to deploy, manage and maintain.



Compact 3-phase power protection with scalable runtime for small data centres and other business critical applications.Features

• APC Smart-UPS VT 30kVA 400V with 3 Battery Modules Expandable to 4/Built-in Maintenance Bypass/Parallel Capable
• Input Connection: Hard Wire 5 wire (3PH+N+G)
• Output Connections: (1) Hard Wire 4-wire (3PH + G), (1) Hard Wire 5-wire (3PH + N + G), (1) Screw Terminals
• Interface Port(s): DB-9 RS-232, SmartSlot
• Valve Regulated Lead Acid battery
• Parallel-redundant capable: Power the connected equipment with multiple UPSs to increase system redundancy
• Parallel-capacity capable: Increases total power capacity by using multiple UPSs simultaneously
• One year repair or replace, Start-Up Service

Specifications

Attributes
Typical backup time at half load	18.3 minutes
Typical backup at full load	5.5 minutes
Waveform Type	Sinewave
Protection for data line	IP 20
Control Panel	Multi-function LCD status and control console
Audible Alarm	Audible and visible alarms prioritized by severity
Compliance
Performance	C-tick,CE,EN 50091-2,EN/IEC 62040-3,IEC 61000-3-2,IEC 61000-3-3,ISO 14001,ISO 9001,VFI-SS-112
Electrical
Battery Type	Valve Regulated Lead Acid
Typical Recharge Time	5 Hours
Output Capacity	30kVA
Output Wattage	24kW
Output Voltage	Configurable for 380, 400 or 415V AC
Max Configurable Capacity	30kVA
Input Voltage Range	304 to 477V AC
Input Configuration	3 Phase
Environmental
Environmental	Operating Temperature 0 to 40�C - Humidity 0 to 95%
Noise Level	55dbA
Filtering
Output Distortion	less than 5% at full load%
Crest Factor	Unlimited
General
Product Family	Smart-UPS VT
Product Type	Uninterruptible Power Supply
Warranty	One year repair or replace,Start-Up service.
Barcode	731304257028
Interfaces/Ports
Input Connection type	Hard Wire 5-wire (3PH + N + G)
Output Connections	(1) Hard Wire 4-wire (3PH + G), (1)Hard Wire 5-wire (3PH + N + G), (1)Screw Terminals
Interface Port	1 x DB-9 RS-232 , 1 x SmartSlot
Physical
Case Colour	Black
In The Box	Smart-UPS VT 30kVA, Battery modules ship installed, Bolt down brackets, CD with software, Installation guide, Power modules ship installed, Start up included, User Manual, Web/SNMP Management Card
Dimensions	55.9cm (W) x 81.3cm (D) x 149.0cm (H) - Weight 536.82kg
