Huawei S5700-28P-LI-AC Mainframe Network Switch (24 10/100/1000 Base-t, 4 1000 Base-x AC 110/220V)

The S5700 series gigabit enterprise switches (S5700 for short) are next-generation energy-saving switches developed by Huawei to meet the demand for high-bandwidth access and Ethernet multi-service aggregation. The S5700 is for use in various enterprise network scenarios. For example, it can function as an access or aggregation switch on a campus network, a gigabit access switch in an Internet data center (IDC)



The S5700 supports IGMP v1/v2/v3 snooping, IGMP filter, IGMP fast leave, and IGMP proxy.The S5700 provides the Multi-VPN-Instance CE (MCE)function to isolate users in different VLANs on a device, ensuring data security and reducing costs.Features

• Powerful support for services
• Comprehensive reliability mechanisms
• Well-designed QoS policies and security mechanisms
• Maintenance-free design and manageability
• PoE function
• High scalability
• Various IPv6 features

Specifications

Electrical
Voltage/Power/Frequency	100 to 240VAC / 50 to 60Hz
Environmental
Environmental	Operating Temperature 0 to 50�C - Humidity 10 to 90%
General
Model Name	S5700-28P-LI-AC
Product Type	Network Switch
Interfaces/Ports
Network Speeds Supported	10/100/1000MBps
Fixed Ports	20 port(s) x RJ-45 , 10/100/1000Mbps ,
Uplink Ports	4 port(s) x
Physical
Dimensions	44.2cm (W) x 31.0cm (D) x 4.36cm (H)
System
Management Capabilities	Stacking (The S5700-HI and S5700S-LI does not support this function.) � MAC Forced Forwarding (MFF) � Virtual cable test � Port mirroring and RSPAN (remote port mirroring) � Remote configuration and maintenance using Telnet � SNMP v1/v2/v3 � RMON � Web NMS � HGMP � System logs and alarms of different levels � GVRP � MUX VLAN � 802.3az EEE (supported by the S5700-LI and S5700HI) � Dying gasp (supported by the S5700-LI) � NetStream (supported by the S5710-EI)
Security	User privilege management and password protection � DoS attack defense, ARP attack defense, and ICMP attack defense � Binding of the IP address, MAC address, interface, and VLAN � Port isolation, port security, and sticky MAC � Blackhole MAC address entries � Limit on the number of learned MAC addresses � 802.1x authentication and limit on the number of users on an interface � AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC � SSH v2.0 � Hypertext Transfer Protocol Secure (HTTPS) � CPU defense � Blacklist and whitelist
