The Edge 72 entry-level business desktop PC delivers the fundamentals; great application performance and reliability, while legendary Lenovo service will keep you online and your customers happy.
Product Description | Lenovo ThinkCentre Edge 72 3493 - Core i3 3220 3.3 GHz - Monitor : none. |
---|---|
Type | Personal computer |
Form Factor | Small form factor |
Localisation | English / United Kingdom |
Processor | 1 x Intel Core i3 (3rd Gen) 3220 / 3.3 GHz ( Dual-Core ) |
Processor Socket | LGA1155 Socket |
Processor Main Features | Intel Extended Memory 64 Technology |
Cache Memory | 3 MB |
Cache Per Processor | 3 MB |
RAM | 4 GB (installed) / 16 GB (max) - DDR3 SDRAM - 1600 MHz - PC3-12800 |
Storage Controller | SATA ( SATA-300 ) |
Hard Drive | 1 x 500 GB - SATA-300 |
Optical Storage | DVD-Writer |
Card Reader | 9 in 1 |
Monitor | None. |
Graphics Controller | Intel HD Graphics 2500 |
Audio Output | Integrated - stereo |
Networking | Gigabit LAN |
Power | AC 120/230 V ( 50/60 Hz ) |
OS Provided | Windows 8 Pro 64-bit / 7 Professional 64-bit Edition downgrade - pre-installed: Windows 7 |
Microsoft Office Preloaded | Includes Office Standard. For Full versions of Office please see THIS LINK |
Dimensions (WxDxH) | 33.6 cm x 38.2 cm x 10.1 cm |
Weight | 6 kg |
Manufacturer Warranty | 1 year warranty - on-site |
General | |
---|---|
Built-in Devices | Speaker |
Colour | Glossy black |
Localisation | English / United Kingdom |
Product Form Factor | Small form factor |
Type | Personal computer |
Audio Output | |
---|---|
Compliant Standards | High Definition Audio |
Sound Output Mode | Stereo |
Type | Integrated |
Cache Memory | |
---|---|
Cache Per Processor | 3 MB |
Installed Size | 3 MB |
Card Reader | |
---|---|
Type | 9 in 1 card reader |
Dimensions & Weight | |
---|---|
Depth | 38.2 cm |
Height | 10.1 cm |
Weight | 6 kg |
Width | 33.6 cm |
Expansion / Connectivity | |
---|---|
Bays | 1 (total) / 0 (free) x external 5.25" x 1/2H ¦ 1 (total) / 0 (free) x internal 3.5" x 1/3H ¦ 1 (total) / 0 (free) x external 1.5" |
Interfaces | 6 x USB 2.0 ( 2 front, 4 rear ) ¦ 2 x microphone ( 1 front, 1 rear ) ¦ 1 x headphones ( 1 in front ) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x VGA ¦ 1 x DVI-D ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x parallel ¦ 1 x serial |
Slots | 2 (total) / 1 (free) x DIMM 240-pin ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 2.0 x16 - low-profile ¦ 2 (total) / 2 (free) x PCIe 2.0 x1 - low-profile |
Graphics Controller | |
---|---|
Graphics Processor | Intel HD Graphics 2500 |
Max Monitors Supported | 2 |
Type | Integrated |
Video Interfaces | VGA, DVI |
Hard Drive | |
---|---|
Capacity | 1 x 500 GB |
Interface Type | SATA-300 |
Spindle Speed | 7200 rpm |
Type | HDD |
Input Device | |
---|---|
Type | Mouse, keyboard |
Keyboard | |
---|---|
Interface | USB |
Keyboard Name | Lenovo Slim USB Keyboard |
Manufacturer Warranty | |
---|---|
Service & Support | 1 year warranty |
Service & Support Details | Limited warranty - 1 year - on-site |
Miscellaneous | |
---|---|
Compliant Standards | RoHS |
Features | Security lock slot (cable lock sold separately), administrator password, hard drive password, power-on password, boot without keyboard or mouse, USB port control, boot sequence control, padlock loop |
Monitor | |
---|---|
Monitor Type | None. |
Mouse | |
---|---|
Features | Scroll |
Interface | USB |
Technology | Optical |
Networking | |
---|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Ethernet Controller | Realtek RTL8111E |
Features | Wake on LAN (WoL) |
Type | Integrated |
Operating System / Software | |
---|---|
Microsoft Office Preloaded | Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC. |
OS Provided | Windows 8 Pro 64-bit / 7 Professional 64-bit Edition downgrade |
Preinstalled OS | Windows 7 |
Software | Windows 8 Pro 64-bit recovery DVD |
Optical Storage | |
---|---|
Type | DVD-Writer - SATA |
Power | |
---|---|
Device Type | Power supply |
Nominal Voltage | AC 120/230 V ( 50/60 Hz ) |
Power Provided | 180 Watt |
Processor / Chipset | |
---|---|
CPU | Intel Core i3 (3rd Gen) 3220 / 3.3 GHz |
CPU Qty | 1 |
CPU Socket | LGA1155 Socket |
Chipset Type | Intel H61 Express |
Max CPU Qty | 1 |
Number of Cores | Dual-Core |
Processor Main Features | Intel Extended Memory 64 Technology |
RAM | |
---|---|
Configuration Features | 1 x 4 GB |
Features | Unbuffered, dual channel memory architecture |
Form Factor | DIMM 240-pin |
Installed Size | 4 GB / 16 GB (max) |
Memory Specification Compliance | PC3-12800 |
Memory Speed | 1600 MHz |
Technology | DDR3 SDRAM |
Storage Controller | |
---|---|
Channel Qty | 3 |
Controller Interface Type | SATA-300 |
Type | 1 x SATA - integrated |
