1 x Socket SP3 (LGA 4094)
AMD EPYC™ 7002 Series
AMD EPYC™ 7003 Series
-
Total Slots :
8 (8-channel, 1DPC)
Capacity :
Max. 2,048GB RDIMM
Memory Type :
DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS
Memory Size :
256GB, 128GB, 64GB, 32GB, 16GB
* Refer to support page for more information
-
Rear
- 4 x PCIe x16 slots (Gen4 x16 link, FH, FL) for dual-slot GPU cards or
8 x PCIe x16 slots (Gen4 x8 link, FH, FL) for single-slot GPU cards
- 2 x PCIe x16 slots (Gen4 x16 link, LP, HL)
Front
- SKU-1:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL)
- SKU-2:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL) or
1 x OCP3.0 slot (Gen4 x8 link) by switching cables
- SKU-3:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL) or
2 x M.2 sockets (Gen4 x4 link, up to 22110 module) by switching cables
-
Storage Controller :
CPU Integrated
Optional kits Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
ASUS PIKE II 3108-8i 8-port SAS 12G RAID card
-
8 x 3.5" Hot-swap Storage Bays
(Backplane Supports 6 x SATA/SAS + 2 x SATA/SAS/NVMe Devices)*
1 x M.2 socket (Gen4 x4 link, up to 22110 on-motherboard)
-
2 x 1GbE LAN ports (RJ45, Intel I350-AM2)
-
Please find the latest GPU support from
https://servers.asus.com/support/GPU
-
4 x USB 3.2 Gen1 ports
-
2 x USB 3.2 Gen1 ports
1 x VGA port
2 x 1GbE LAN ports (RJ45)
1 x Management port (RJ45)
-
Front :
1 x Power Button/LED
1 x Location Button/LED
2 x LAN LED
1 x Message LED
1 x HDD Access LED
Rear :
1 x Power Button/LED
1 x Location LED
1 x Message LED
1 x HDD Access LED
-
Please find the latest OS support from
https://servers.asus.com/support/os
-
ASUS Control Center Enterprise (in-band)
ASMB9-iKVM (out-of-band/BMC AST2500)
-
BSMI, CB, CE, RCM, FCC(Class A)
-
800 x 440 x 88.9mm
-
2U
-
Net Weight: 34 Kg.
Gross Weight: 44 Kg.
-
1+1 Redundant 1600W 80 PLUS Platinum Power Supply C-14 power inlet
Rating: 100-127Vac/200-240Vac,12.9A/9.5A,50-60Hz
1+1 Redundant 2200W 80 PLUS Platinum Power Supply C-20 power inlet
Rating: 100-127Vac/200-240Vac,14A/12.6A,47-63Hz
-
Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
-
*Default supports 2 x NVMe SSD. If users need to install 4 x NVMe SSD, please remove Slimline cables from the front PCIe riser board , and re-connect the cables to the backplane.
** There is a MicroSD slot on motherboard allowing you to install a MicroSD card to save BMC events.
***We also provide special GPU riser cards (with PCIe-switch) could support 8 single-slot GPU cards (x16 link for each). If customers need the customization, please contact ASUS sales representative for detail.
