See Parts List
|
|
|
 |
|
Part Number
|
Qty
|
Description
|
| Motherboard / Chassis |
MBD-X11DDW-NT
CSE-116AC2-R706WB2 |
1
1 |
Super X11DDW-NT Motherboard
1U Chassis |
| Backplane |
BPN-SAS3-116A-N2 |
1 |
10-port 1U SAS3 12Gbps Hybrid backplane, support up to 8x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices |
| Cable 1 |
CBL-0160L |
2 |
NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt) |
| Cable 2 |
CBL-0335L |
1 |
CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG |
| Cable 3 |
CBL-SAST-0388L-02 |
1 |
MINI SAS-4 SATA,INT,75/75/90/90CM,90CM SB,30AWG |
| Cable 4 |
CBL-SAST-0507-01 |
2 |
MINI SAS HD-MINI SAS,6G,INT,80CM,SB,28AWG |
| FAN 1 |
FAN-0101L4 |
4 |
40x56,4 Pin PWM,Primary for SC809,111, Sec.for SC816,819,808 |
| Parts |
MCP-120-00029-0N |
2 |
Blank FH L bracket without SCSI cutout for SC815,823 |
| Parts |
MCP-120-00030-0N |
1 |
Blank LP L-bracket (1 raw of capsule hole) |
| Parts |
MCP-150-00015-0B |
2 |
Rubber pad, 3.0mm H, 10x10mm |
| Drive Tray(s) |
MCP-220-00047-0B |
10 |
Black gen 3rd hot-swap 2.5inch HDD tray |
| Power Supply |
MCP-250-00009-0N |
1 |
SC113 Redundant Power Distributor Cover |
| Air Shroud |
MCP-310-19002-0N |
1 |
SC815/113/116 Intel DP X9, X8 PC air shroud, 12x13MB |
| Air Shroud |
MCP-310-19019-0B |
2 |
SC113/SC116/SC815/SC515, DP X11DDW Mylar air shroud |
| Fan Holder |
MCP-320-00027-0B |
24 |
Plastic pin for 40x28, 40x56 fan |
| Fan Holder |
MCP-320-00028-0B |
1 |
Fan holder for 6pcs 40x56 fan, assemble-able for SC819/SC119/SC818/SC116 |
| Fan Holder |
MCP-320-00061-0B |
1 |
CR foam for air block in SC113/SC116/SC815 |
| Fan Holder |
MCP-340-00035-0B |
2 |
Dummy fan 40x56mm for 40x56 counter-rotating fan (cost-effective) |
| Manual |
MNL-2004-QRG |
1 |
1029P-WTRT Quick Reference Guide,HF,RoHS. |
| Power Supply |
PWS-706P-1R |
2 |
1U 750W redundant power width 54.5mm(Platinum),HF,RoHS/REACH,PBF |
| Riser Card |
RSC-R1UW-2E16 |
1 |
1U LHS WIO Riser card with two PCI-E x16 slots |
| Riser Card |
RSC-R1UW-E8R |
1 |
1U RHS WIO Riser card with one PCI-E x8 slot |
| Heatsink / Retention |
SNK-P0067PSMB |
2 |
1U Passive High Performance Front CPU Heat Sink w/ an 18-mm Wide Middle Air Channel for X11 Purley Platform Equipped w/ a Narrow Retention Mechanism/Bolster |
|
|
|
|
|
| |
Part Number |
Qty |
Description |
| NVMe Drive Tray with Lock |
MCP-220-00127-0B |
- |
Black gen-3 2.5" NVMe drive tray (Orange tab. PUSH button with key lock) |
| NVMe Cable |
CBL-SAST-0929 |
- |
OCuLink source to MiniSAS HD target V.91,INT,PCIe NVMe SSD, 57CM,34AWG,RoHS |
| CachVault(s) |
BTR-CV3108-1U1
BTR-TFM8G-LSICVM02 & BKT-BBU-BRACKET-05
BTR-TFM8G-LSICVM02 & MCP-240-00127-0N |
1
-
- |
CacheVault for Broadcom 3108 with SuperCap mounting in 1U 40x56 fan tray
CacheVault for Broadcom 3108; SuperCap mounting bracket for PCI-E location
CacheVault for Broadcom 3108; SuperCap mounting bracket for 2.5" HDD location |
SuperCap for
AOC-S2208L-H8IR |
BTR-0024LH-LSI00297 & BKT-BBU-BRACKET-05
BTR-0024LH-LSI00297 & MCP-240-00127-0N |
-
- |
SuperCap TFM to be used w/ Supermicro AOC-S2208L-H8IR; SuperCap mounting bracket for PCI-E location
SuperCap TFM to be used w/ Supermicro AOC-S2208L-H8IR; SuperCap mounting bracket for 2.5" HDD location |
| Cooling Fan (required if AOM is installed) |
FAN-0101L4 |
- |
40x40x56 mm, 14.4K-10.7K RPM Counter-rotating Cooling Fan |
Storage Controller
Card(s) & Cables(s) |
AOM-S3108M-H8 &
2x CBL-SAST-0531
AOC-S3108L-H8IR-16DD
& 2x CBL-SAST-0531
AOC-S3008L-L8i &
2x CBL-SAST-0531
AOC-S3008L-L8e &
2x CBL-SAST-0531
AOC-S2308L-L8e &
2x CBL-SAST-0631
AOC-S2308L-L8i &
2x CBL-SAST-0631
AOC-S2208L-H8iR &
2x CBL-SAST-0631 |
- |
Supermicro Low Profile 12Gb/s Eight-Port SAS
Internal Mezzanine RAID Adapter, RAID 0, 1, 5, 6, 10, 50, 60
Standard LP, 8 internal ports (12Gb/s) Gen-3, 16HDD;
RAID 0, 1, 5, 6, 10, 50, 60
Standard LP, 8 internal ports (12Gb/s) Gen-3, 63HDD;
RAID 0, 1, 10
Standard LP, 8 internal ports (12Gb/s) Gen-3, 122HDD;
HBA
Standard LP, 8 internal ports (6Gb/s) Gen-3, 122HDD;
HBA (Cable included in system)
Standard LP, 8 internal ports (6Gb/s) Gen-3, 63HDD;
RAID 0, 1, 10 (Cable included in system)
Standard LP, 8 internal ports (6Gb/s) Gen-3, 240HDD;
RAID 0, 1, 5, 6, 10, 50, 60 (Cable included in system) |
| Network Card(s) |
AOC-SGP-i2
AOC-SGP-i4
AOC-SG-i2
AOC-SG-i4
AOC-STG-b4S
AOC-STGN-i2S
AOC-STGN-i1S
AOC-STG-i2T
AOC-STG-i2 |
-
-
-
-
-
-
-
-
- |
Standard LP, 2x GbE RJ45, PCI-E x4, Intel® i350AM2
Standard LP, 4x GbE RJ45, PCI-E x4, Intel® i350
Standard LP, 2x GbE RJ45, PCI-E x4, Intel® 82575EB
Standard LP, 4x GbE RJ45, PCI-E x8, Intel® 82576EB
Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom® BCM57840S
Standard LP, 2x 10GbE SFP+, PCI-E x8, Intel® 82599ES
Standard LP, 1x 10GbE SFP+, PCI-E x8, Intel® 82599ES
Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel® X540
Standard LP, 2x 10GbE CX4, PCI-E x8, Intel® 82598EB |
| Front Bezel |
MCP-210-11601-0B |
1 |
Black Front Bezel for SC113, SC113M, SC116, SC119, SC119U, SC514 (No LED indicator support) |
| TPM security module (optional, not included) |
AOM-TPM-9670V |
1 |
SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor |
| TPM security module (optional, not included) |
AOM-TPM-9671V |
1 |
SPI capable TPM 1.2 with Infineon 9670 controller with vertical form factor |
| Global Services & Support |
OS4HR3/2/1
OSNBD3/2/1 |
-
- |
3/2/1-year onsite 24x7x4 service
3/2/1-year onsite NBD service |
| Software |
SFT-OOB-LIC |
1 |
OOB Management Package (per node license) |
| Software |
SFT-DCMS-Single |
1 |
DataCenter Management Package (per node license) |
|
|
|
