Supermicro SuperServer SYS-5018D-FN8T

SYS-5018D-FN8T

Sorry, but this product is no longer available to purchase online.

Please contact us to discuss alternative products which may be suitable.

Looking for Compatible Products?

More from this brand

Product Description

Product SKUs

SYS-5018D-FN8T	SuperServer 5018D-FN8T (Black)


Motherboard

Super X10SDV-TP8F


Processor/Cache

CPU	Intel® Xeon® processor D-1518, 2.2GHz; CPU TDP support 35W FCBGA 1667
Cores / Cache	4 Cores, 8 Threads / 6MB


System Memory

Memory Capacity	4x DDR4 DIMM sockets Supports up to 128GB DDR4 ECC RDIMM Supports up to 64GB DDR4 ECC/non-ECC UDIMM
Memory Type	2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM
DIMM Sizes	32GB, 16GB, 8GB, 4GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)


On-Board Devices

SATA	SoC controller for SATA3 (6Gbps) ports
Network Controllers	Dual 10G SFP+ from D-1500 SoC Quad 1GbE with Intel I350-AM4 Dual 1GbE with Intel I210
IPMI	IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Dedicated RJ45 IPMI LAN port
Graphics	BMC integrated ASPEED AST2400


Input / Output

SATA	4x SATA3 (6Gbps) ports
LAN	2x 10G SFP+ ports 6x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port
USB	2x USB 3.0 ports (rear)
DOM	1x SATA DOM (Disk on Module) power connector
VGA	1x VGA Port
Others	TPM 2.0 header


Chassis

Form Factor	1U Rackmount
Model	CSE-505-203B


Dimensions and Weight

Height	1.7" (43mm)
Width	17.2" (437mm)
Depth	9.8" (249mm)
Weight	Net Weight: 8 lbs (3.63 kg) Gross Weight: 12 lbs (5.44 kg)
Available Colors	Black


Front Panel

Buttons	Power On/Off button System Reset button
LEDs	Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED Information LED (temp., status)


Expansion Slots

PCI-E	1x PCIe 3.0 x8 slots M.2 PCIe 3.0 x4, M Key 2242/2280/22110 Mini-PCIe with mSATA support


Drive Bays

HDD	1x 3.5" or 4x 2.5" fixed drive bays with bracket


System Cooling

Fans	Passive Heatsink, 40mm chassis fan


Power Supply

200W Low Noise AC-DC power supply with PFC
AC Voltage	100 - 240V, 50-60Hz, 2.6 Amp Max
+5V	8.0 Amp (max.)
+5V standby	2.0 Amp (max.)
+12V	16 Amp (max.)
-12V	0.5 Amp (max.)
+3.3V	8.0 Amp (max.)
Certification	Gold Certified


System BIOS

BIOS Type	128Mb SPI Flash with AMI BIOS
BIOS Features	PCI 3.0 ACPI 5.0 USB Keyboard support Hardware BIOS Virus protection SMBIOS 2.8 UEFI 2.4 RTC (Real Time Clock) Wakeup


Operating Environment / Compliance

RoHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C to 40°C (50°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)

See Parts List


Parts List - (Items Included)

	Part Number	Qty	Description
Motherboard / Chassis	MBD-X10SDV-TP8F CSE-505-203B	1 1	Super X10SDV-TP8F Motherboard 1U Chassis
Cable 1	CBL-0082L	1	Y split , big 4 pin to two RA SATA power extension 15cm, 18AWG
Cable 2	CBL-SAST-0538	2	SATA,INT,ROUND,ST-RA,29CM,30AWG
FAN 1	FAN-0065L4	3	4028mm 13K RPM 4-PIN PWM FAN for SC813MF, SC113M
Drive Tray(s)	MCP-220-00051-0N	2	Single 2.5
Rear Window	MCP-240-00091-0N	1	1U universal riser card bracket for standard chassis,HF,RoHS/REACH,PBF
Parts	MCP-260-00100-0B	1	1U I/O Shield
Fan Holder	MCP-320-81302-0B	3	Optional fan tray for one 40x28mm fan in SC813T/SC813LT-single PWS (Fan tray only)
Riser Card	RSC-RR1U-E8	1	RSC-RR1U-E8
Power Supply	PWS-203-1H	1	1U 200W Multi-output 80Plus Gold PWS


Optional Parts List

	Part Number	Qty	Description
Air Shroud	MCP-310-50502-0B	-	Air shroud
HDD Bracket	MCP-220-00044-0N	-	Retention Bracket for up to 2x 2.5" HDD
HDD Bracket	MCP-220-00051-0N	-	Retention Bracket for 1 x 2.5" HDD
SuperDOM	-	-	Supermicro SATA DOM Solutions [Details]
Hide Parts List

* 1x 3.5" or 2x 2.5" SATA3 with riser card
