• Tool-less design supports quick installation and easy maintenance:
- Tool-less 2.5" drive trays
- Tool-less slide rail
• Supports 4 x 12G 3.5" hot swap drive bays
• Includs 300W redundant power supply
• Support 1 full height expansion slot
• One front access USB 3.0 port
RSC-1DTS is a T-series 1U SAS/SATA storage server chassis supports external 4 x 12G 3.5" hot swap and internal 4 x 2.5" (9mm) drive bays. This environmentally friendly solution features high-efficiency power supply, SGCC pre-plated steel, tool-less ball-bearing mounting rail, easy-swap PWM fans, and overall short depth, offering a cost-effective solution ideally suited for a broad range of applications, and especially space-concerned users. (Power supply is included. Motherboard is not included.)
Dimensions (W x D x H) |
• mm: 483 x 560 x 43.5 • inches: 17 x 22 x 1.72 |
Industry Standard |
EIA-RS310D |
Material |
SGCC |
Color |
Front Panel: Black |
Cooling |
Middle: 4 x 40x28mm PWM fans |
Power Supply |
Standard: 300W 1+1 redundant Option: 400W single PSU |
Expansion Slot |
1 full height |
Front Panel |
System power on/off and system reset, 1 x USB 3.0 port |
LED Indicators |
• Power • HDD • LAN |
System Board |
Up to 12"(W) x 9.6"(D) ATX MB |
Drive Bays |
• External: 3.5" hot swap x 4 • Internal: 2.5" x 4 (9mm) |
Backplanes |
4-port with SFF-8643 connector supports 12G |
Storage Temperature |
0°C(32°F) ~ 50°C(122°F) |
Humidity |
5% ~ 95% non-condensing |
Gross Weight (w/ PSU & Rail) |
• kgs: 14 • lbs: 30.9 |
Package Dimension (W x D x H) |
• mm: 588 x 730 x 178 • inches: 23.1 x 28.7 x 7 |
Cubic Feet |
4.2 |
Container Load Quantity |
• 20’: 200 • 40’: 400 • 40’H: 450 |
Mounting |
Standard: 28” tool-less slide rail |
