The IPC- C2KTS is a T-series 2U 8-bay SAS/SATA storage server chassis that has been designed around quick installation, easy maintenance and cost competitive, with tool-less design 3.5” and 2.5” hard drive carriers and top cover. Fan are Easy swap design X3 with low-power consumption, SPGC pre-plated steel with minimal paint , offering a cost- effective solution ideally suited for a broad range of application. (Power supply is included. Motherboard is not included).
Dimensions (W x D x H) (with chassis ears)
• mm : 430 x 560 x 88
• inches : 17 x 22 x 3.5
Industry Standard
EIA-RS310D
Material
Heavy-duty preplated SGCC cold-rolled steel
Color
Front Panel : Black
Cooling
Middle : 3 x 80x38mm PWM & low-power consumption hot swap fans
Power Supply
550W Single Industrial PSU PMBus 1.2 80+ Bronze
Expansion Slots
7 x low profile
Front Panel
• Power on/off
• System reset
• 1 x USB 3.0 port
LED Indicators
• Power
• LAN
• Drive
• Alert
System Board
Up to 12” x 9.6” ATX / SSI EEB 3.6 compliant MB
Drive Bays
• External : 8 x 3.5” hot swap
• Internal : 2 x internal and 1 x Slim Optical
Backplane
2 x 4-port 12Gb SATA/SAS backplanes with SFF-8643 connector
Storage Temperature
0°C(32°F) ~ 50°C(122°F)
Humidity
5% ~ 95% non-condensing
Gross Weight (w/ PSU & Rail)
• kgs : 23.5
• lbs : 51.80
Package Dimension (W x D x H)
• mm: 577 x 835 x 234
• inches: 22.7 x 32.8 x 9.2
Cubic Feet
3.88
Container Load Quantity
• 20’: 200
• 40’: 460
• 40’ H: 506
Mounting
Standard : 28” tool-less slide rail
Sorry there are no compatible products listed. Please contact us to discuss options available for this product.
There are currently no downloads available for this product. If you need a specific document, such as a manual, installation guide or datasheet please contact us and we would be happy to help.
There are currently no reviews against this product. Be the first to write a review!
