AIC 2U Rugged Short Chassis 1 x 5.25" + 1 x 3.5" External + 3 x 3.5" + 1 x Slim Optical with 300 watt PSU Inc. (Low Profile Version)

Key Features

• Rugged design to meet most applications.
• Short depth design for space critical application
• Front access dual USB ports
• 2 x middle fans + 1 x rear blower fan for superior cooling
• 300 watt PSU Included
• Optimised For 7 x Low Profile PCI Cards

Features And Benefits

The IPC-C2A-BAS3-LP chassis is designed specifically for Entry-level server, Computer Telephony and Appliance applications with 17” depth and excellent air flow. It supports a full range of single processor-based ATX size motherboards.

Dimensions (W x D x H) (with chassis ears)
• mm : 482.6 x 431.8 x 88.8
• inches : 19 x 17 x 3.5
Industry Standard
EIA-RS310D
Material
Heavy-duty SGCC cold-rolled steel
Color
Black
Cooling
• Middle : 2 x 80x25mm fans
• Rear : 1 x 97mm blower
Power Supply
Please see Optional Product for details *Industrial PSU Only
Expansion Slots
• 7 low profile
Front Panel
• Power on/off
• System reset
• 2 x USB ports
LED Indicators
• Power
• LAN
• Drive
System Board
Up to 12”(W) x 9.6”(D) ATX compliant MB
Drive Bays
• External : 1 x 5.25”, 1 x 3.5” & 1 x Slim DVD-ROM
• Internal : 3 x 3.5”
Storage Temperature
0°C(32°F) ~ 50°C(122°F)
Humidity
5% ~ 95% non-condensing
Gross Weight (w/ PSU; w/o Rail)
• kgs : 12.7
• lbs : 28
Package Dimension (W x D x H)
• mm : 588 x 598 x 248
• inches : 23.1 x 23.5 x 9.8
Cubic Feet
2.8
Container Load Quantity
• 20’ : 340
• 40’ : 695
• 40’ H : 940
Mounting
Please see Optional Product for details
* All specifications are subject to change without notice
