In-Win IW-R200-02N - 2U Feature Rich Short Depth Server Chassis

Standard

EIA-RS310D

M/B Form Factor

ATX (12" x 9.6")

Dimensions (D x W x H)
w/o Front Door

504 x 482.6 x 88.9 mm (19.8" x 19" x 3.5")

Drive Bay

External: 5.25” x 2
Internal: 3.5" x 4

Power Supply

Supports
▪ Form Factor: PS2 or 2U 1+1 Redundant
▪ Watt: up to 500W

Indicator

Power Status, HDD, LAN Activity LEDs

Front Control Panel

Power Switch, System Reset, USB 2.0 x 2

Chassis Security

Intrusion Switch

Cooling Fan

Supports 80 x 25 mm PWM Fan x 2

Expansion Slot

Low Profile PCI Slot x 7 or Full Height PCI Slot x 3 (via riser card)

Material

Material: SGCC
Thickness: 1.2 mm

Rail Kit

Supports 28" King slide Rail, Ball-bearing

Packaging Dimensions
(D x W x H)

717 x 552 x 268 mm

Shipping Info.

Net Weight: 7.97 kg
Gross Weight: 10.94 kg

Container Info.

Single Packing:
20’: 235pcs
40’: 520pcs
40’HQ: 640pcs

* The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make final modifications.
* Above image for reference only. All hardware components are not included.
