Supermicro CSE-847BE1C-R1K28LPB

CSE-847BE1C-R1K28LPB

Sorry, but this product is no longer available to purchase online.

Please contact us to discuss alternative products which may be suitable.

Looking for Compatible Products?

More from this brand

Product Description

Product SKUs

CSE-847BE1C-R1K28LPB	SuperChassis 847BE1C-R1K28LPB


Form Factor

4U Chassis for motherboard support size: (12" x 10") (13.68" x 13") (9.6" x 9.6")


Processor Support

Single and Dual Intel® and AMD processors


Dimensions

Height	7" (178 mm)
Width	17.2" (437 mm)
Depth	27.5" (699 mm)
Gross Weight	91 lbs (41.28 kg)
Packaging (W x H x L)	27.2" (691 mm) x 17.4" (442 mm) x 39.6" (1006 mm)
Available Color	Black


Expansion Slots

7 low-profile expansion slot(s)


Drive Bays

36 x 3.5" hot-swap SAS/SATA drive bay with SES3 Optional 2 x 2.5" hot-swap drive bay


Backplane

12-port 2U SAS3 12Gbps single-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD


Peripheral Drives

Optional 2 x 3.5" internal fixed drive bay Optional 4 x 2.5" internal fixed drive bay


Front Panel

Buttons	Power On/Off button System Reset Button
LEDs	2 Network Activity LEDs Fan Fail/System Over Heat LED HDD activity LED Power Status LED Unit Identification (UID) LED


Motherboard (for CSE- 847BE1C-R1K28LPB)

X9DR3-F	X9DRi-F
X9DRH-7F	X9DRH-7TF
X9DRH-iF	X9DRH-iTF
X9DRD-7LN4F-JBOD	X9DRD-EF
X9DRD-7LN4F	X9DB3-TPF
X9DB3-F	X9DBi-TPF
X9DBi-F	X9DRH-iF-NV
X10DRi-LN4+	X10DRi-T4+
X10DRC-T4+	X10DRC-LN4+
X10DRi	X10SRH-CLN4F
X10DRi-T	X10DRH-I
X10DRH-iT	X10DRH-CT
X10DRH-C	X10DRH-iLN
X10DRH-CLN4


Servers (for CSE- 847BE1C-R1K28LPB)

6047R-E1CR36L	5048R-E1CR36L
6047R-E1CR36N	6048R-E1CR36H
6048R-E1CR36L	6048R-E1CR36N

Systems Cooling

Fans	7 x 8cm (7000 RPM) hot-swap PWM cooling fan(s)


System Monitoring

Chassis intrusion switch


Operating Environment (System)

Operating Temperature Range	5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range	-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range	8% - 90% (non-condensing)
Non-Operating Relative Humidity Range	5% - 95% (non-condensing)


Power Supply
1U 1280W Redundant Platinum 95%+ Super Quiet Power Supply with PMbus
Power Efficiency	95%
Total Output Power and Input	1000W with Input 100 - 140Vac 1280W with Input 180 - 240Vac
AC Input Frequency	50-60Hz
Dimensions (L x W x H)	336 x 76 x 40 mm
Output Type	Backplanes (gold finger)
+12V	Max: 83A / Min: 0.5A (100Vac - 140Vac) Max: 106.7A / Min: 0.5A (180Vac - 240Vac)
+5Vsb	Max: 4A / Min: 0A
Power Distributor	PDB-PT847-8824 O/P: 12V/135 +5V Max: 100 +3.3V Max: 30 -12V Max: 0.6
Certification	Platinum Certified


Regulatory (Power Supply)

Power Supply Safety / EMC	BSMI CCC CE/EMC FCC class B TUV/CB UL/CUL


Standard Parts List

	Part Number	Qty	Description
Air Shroud	MCP-310-49004-0N	1	SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB
HD Backplane	BPN-SAS3-826EL1	1	12-port 2U SAS3 12Gbps single-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD
HD Backplane	BPN-SAS3-846EL1	1	24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD
Cable(S)	CBL-0071L	1	CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG
Cable(S)	CBL-0160L	2	NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt)
Cable(S)	CBL-0217L	1	CBL,CNTL PANEL CONVERTER,FOR SC826/846,FFC,16PIN,22CM
Fan(s)	FAN-0126L4	7	80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing
Front Panel	MCP-280-82601-0N	1	Front control board adapter (TB826) for SC216,826,936,846
Drive Tray(s)	MCP-220-00075-0B	36	Black gen 5.5 hot-swap 3.5"; HDD tray
Drive Tray(s)	MCP-220-84708-ASM	1	SC847B LP MB Tray assembly,HF,RoHS/REACH
Power Distributor	PDB-PT847-8824	1	24pin standard output with 5V high current 100Amp power distributor board for SC847
Power Supply & Accessory	PWS-1K28P-SQ	2	1U 1280W, redundant single output power supply
Mounting Rail(s)	MCP-290-00057-0N	1 set	Rail set, quick/quick, default for 4U 17.2"; W
Mounting Rail(s)	MCP-410-00007-0N	1	Rail screw bag


Optional Parts List

	Part Number	Qty	Description
Cable	CBL-SAST-0531	-	Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s
Cable	CBL-SAST-0532	-	Internal Mini-SAS HD to Mini-SAS HD 50cm,30AWG,12Gb/s
Drive Trays	MCP-220-84701-0N	-	Internal drive bay for one 3.5" HDD or two 2.5" HDD
Drive Trays	MCP-220-00043-0N	-	3.5" convert to 2.5" hot-swap HDD Tray
Front Bezel	MCP-210-84601-0B	-	Front Bezel Cover, Black with Key Lock
Mounting Rail	MCP-290-00058-0N	-	19" to 26.6" rail set, Quick Release, Tool-less
Mounting Rail	MCP-290-00060-0N	-	Square hole to round hole rail adaptor set
HDD Kit	MCP-220-82609-0N	-	Rear 2.5 x 2 Hot swap HDD kit for 216B/826B/417B/846X/847B
Drive Trays	MCP-220-00043-0N	-	Black hotswap gen 4 3.5 to 2.5 HDD tray
Drive Trays	MCP-220-84701-0N	-	SC847 internal drive tray for one 3.5
Cable	CBL-SAST-0531-01	-	Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s [FCI],RoHS/REACH
Cable	CBL-SAST-0532	-	Internal Mini-SAS HD to Mini-SAS HD 50cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF
Front Bezel	MCP-210-84601-0B	-	Black Front Bezel For SC846 Chassis
Rail	MCP-290-00058-0N	-	Short rail set, quick release, 19.6"~26.9" Extendable Length
Rail	MCP-290-00061-0N	-	Non-threaded rail adapter optional for round thread rack
HDD Kit	MCP-220-82616-0N	-	12G 2.5x2 Drive Kit w/ Status LED (216B/826B/417B/846X/847B
