Supermicro SuperChassis 417E16-R1400LPB (Black)

CSE-417E16-R1400LPB

Sorry, but this product is no longer available to purchase online.

Please contact us to discuss alternative products which may be suitable.

Looking for Compatible Products?

More from this brand

Product Description

Product SKUs

CSE-417E16-R1400LPB	SuperChassis 417E16-R1400LPB (Black)


Form Factor

4U chassis support for motherboards up to size ATX, E-ATX, 13.68" x 13"


Processor Support

Supports dual, single Intel® / AMD processors


Dimensions

Height	7" (178mm)
Width	17.2" (437mm)
Depth	27.5" (699mm)
Gross Weight	80 lbs (36.3 kg)
Available Colors	Black


Expansion Slots

7x Low-profile expansion slots


Drive Bays

Server Chassis	72x (48 front + 24 rear) 2.5" Hot-swap HDD bays SAS or enterprise SATA HDD only recommended


Backplane

HDD Backplane supports 72 SAS hard drives (48 front + 24 rear) E16: Single Expander chip supports SAS2 (6Gb/s)


Front Panel

Buttons	Power On/Off button System Reset button
LEDs	Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED Power Fail LED


System Cooling

Fans	7x 8cm hot-swap cooling fans Redundant cooling


System Monitoring

Chassis intrusion switch



Operating Environment (System)

Operating Temperature Range	5°C ~ 35°C (41°F ~ 95°F)
Non-Operating Temperature Range	-40°C ~ 60°C (-40°F ~ 140°F)
Operating Relative Humidity Range	8% ~ 90% (non-condensing)
Non-Operating Relative Humidity Range	5% - 95% (non-condensing)


Power Supply

1400W high-efficiency (1+1) redundant power supply with PMBus
AC Input	1100W Output @ 100-140V, 13.5-9.5A, 50-60Hz 1400W Output @ 180-240V, 9.5-7.0A, 50-60Hz
DC Output	1100W: +12V/92A; +5Vsb/4A 1400W: +12V/116A; +5Vsb/4A
With Distributor	+5V: 100 Amp +3.3V: 30 Amp -12V: 0.6 Amp
Certification	Gold Certified [ Test Report ]


Regulatory (Power Supply)

Power Supply Safety / EMC	USA - UL listed, FCC Canada - CUL listed Germany - TUV Certified Europe/CE Mark EN 60950/IEC 60950-Compliant


Standard Parts List

	Part Number	Qty	Description
Chassis	CSE-417E16-R1400LPB	1	4U Chassis (Black) - 417E16-R1400LPB
Backplane	BPN-SAS2-216EL1	3	BPN-SAS2-216EL1
Power Supply	PWS-1K41P-1R	2	1400W 1U GOLD LEVEL PWS W/ PM BUS & WX3
Power Distributor	PDB-PT416-8824	1	SC416 24PIN OUTPUT PDB SUPPORT X8
Air Shroud	MCP-310-49004-0N	1	SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB
Cable 1	CBL-0160L	2	NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt)
Cable 2	CBL-0071L	1	ROUND 16 pin TO 16 PIN RIBBON FP CABLE 30
Cable 3	CBL-0088L	7	10.5\", 4 PIN MIDDLE FAN POWER EXTENSION (PWM). 24AWG
Cable 4	CBL-0217L	1	16 pin control panel converter cable for SC826,846, 22cm, PBF
Fan 1	FAN-0126L4	7	80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing
Front Panel	MCP-280-82601-0N	1	Front control board adapter (TB826) for SC216,826,936,846
Drive Tray(s)	MCP-220-00047-0B	72	Black gen 3rd hot-swap 2.5inch HDD tray
Mounting Rails	MCP-290-00057-0N	1 set	Rail set, quick/quick, default for 4U 17.2\"W
Rear Window	MCP-240-82506-0N	1	LP Rear Window for SC825,825M,826,213,216
Cooling Fan(s)	FAN-0099L4	7	80X38MM 4PIN PWM FAN W/HUS FOR SC828, PBF
