Compliance | |
Standards Compliance | 802.1d Bridging � 802.3x BackPressure/ Flow Control |
CPU | |
Processor | 400MHz |
Electrical | |
Voltage/Power/Frequency | 100 to 240VAC / 54W |
Power Cord | UK Country Specific |
Environmental | |
Heat Dissipation | 184.41BTUs per Hour |
Environmental | Operating Temperature 0 to 45�C - Humidity 10 to 90% |
General | |
Barcode | 0767035181769 |
Interfaces/Ports | |
Fixed Ports | 48 port(s) x 10/100Mbps , (48 10/100 ports) |
Network Slots | (2 Combo Ports (SFP/RJ45)) |
Console Ports | 1 x DB-9, RS-232 |
Memory | |
Flash Memory | 16MB |
Memory (Maximum) | 64MB |
Performance | |
MAC Addresses | 8,000 |
Mean Time Between Failure (MTBF) | 314,322 Hours |
Packet Forwarding Rate | 10 Mbps: 14,880 pps � 100 Mbps: 148,800 pps � 1000 Mbps: 1,488,000pps |
Port Bandwidth | 10/100/1000Mbps |
Stacking Capabilities | Up to 6 units |
Physical | |
Mounting Type | 19 inch rack-mountable |
Dimensions | 44.0cm (W) x 25.7cm (D) x 4.3cm (H) - Weight 3.38kg |
System | |
Management Capabilities | WEB, CLI, Serial � RFC 1157 SNMPv1/v2c � RFC 2570 SNMPv3 � RFC1213 MIB-II � RFC 1215 TRAP MIB � RFC1493 Bridge MIB � RFC 2863 Interfaces group MIB � RFC 1643 Ethernet like MIB � RFC 1757 RMON 4 groups: � Stats, History, Alarms, Events � RFC 2674 802.1Q MIB � RFC 1866 HTML � RFC 2068 HTTP � RFC 854 Telnet � RFC 783 TFTP |
Certifications | Safety UL 1950 (UL/cUL), EN60950 (TUV) � EMI FCC Class A, EN55022 Class A,VCCI Class A, C-Tick, EN61000-3-2, EN61000-3-3 � Immunity EN55024 � RoHS compliant |
Resiliency/Redundancy | 802.1D Spanning Tree Protocol � 802.1W Rapid Spanning Tree � 802.1s Multiple Spanning Tree � 802.3ad LACP Link Aggregation (with up to 8 members per group and up to 8 groups per device) |
Security | Management Security: user name and password protection � SSHv2 for Telnet management � SSLv3 for WEB management � RFC 1492 TACACS+ � RFC 2138 RADIUS Authentication � IEEE 802.1x Port-based network access control � Guest VLANs |
There are currently no reviews against this product. Be the first to write a review!
Sorry there are no compatible products listed. Please contact us to discuss options available for this product.
There are currently no downloads available for this product. If you need a specific document, such as a manual, installation guide or datasheet please contact us and we would be happy to help.
