Dimension:
240.00x100.00x70.00 (mm)
9.45x3.94x2.76 (inch)
AC Input:
VOLTAGE: 90 ~ 264 VAC FULL RANGE
FREQUENCY: 47 ~ 63 HZ
INPUT CURRENT: 10.0A ( RMS ) FOR 115VAC, 5.0A ( RMS ) FOR 230 VAC
INRUSH CURRENT: 50A MAX. FOR 115 VAC, 100A MAX. FOR 230 VAC
POWER FACTOR CORRECTION: PFC CAN REACH THE TARGET
OF 95%/90% AT 115/230VAC, FULL LOAD
DC Output:
Output Voltage/ Output Current Min./ Output Current Max./ Output Ripple&Noise Max
+5V 0.5 25.00 60mV
+12V 2 53 120mV
-12V 0 0.5 120mV
+3.3V 0.5 25 60mV
+5VSB 0.05 3 60mV
Features:
‧TEMPERATURE RANGE: OPERATING 0℃ --- 50℃, STORAGE -20℃ --- 80℃
‧HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
‧EFFICIENCY: 87%-90% TYPICAL AT 115V, FULL LOAD
‧POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
‧OVER POWER PROTECTION
‧OVER VOLTAGE PROTECTION
‧SHORT CIRCUIT PROTECTION
‧EMI: FCC CLASS B, CISPR22 CLASS B
‧SAFETY: TO MEET UL, CUL, TÜV, CCC
‧COOLING: ONE 60mm DC FAN
‧MEET IEC-1000-3-2 CLASS D
*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
